ASME VIII-1 Certified Floating Head Heat Exchanger | TEMA AHS Type, Corrosion-Resistant Alloy Construction

Name: ASME VIII1 Certified Floating Head Heat Exchanger TEMA AHS Type CorrosionResistant Alloy Construction
Brand: YUHONG
Price: 1 USD

Wholesale ASME VIII-1 Certified Floating Head Heat Exchanger | TEMA AHS Type, Corrosion-Resistant Alloy Construction from china suppliers

Brand Name : YUHONG

Model Number : Floating Head Heat Exchanger, TEMA AHS Type

Certification : ASME BOILER & PRESSURE VESSEL CODE SECTION VIII DIV.1

Place of Origin : CHINA

MOQ : 1 SET

Price : Depend on drawing

Payment Terms : T/T, L/C, D/A

Supply Ability : 60 SETS/MONTH

Delivery Time : 20-80 days

Packaging Details : Ply-wooden Case /Iron Case/ Bundle with plastic Cap etc.

Fixed and floating tubesheet : SA516 GR.485

Tubes : SA179

Floating head cover : SA516 GR.485

Floating flange : SA105

Backing ring : SA105

Baffles : SA36

Tie rods : SA36

Spacers : SA179

Skid bars : SA36

Contact Now

ASME VIII-1 Certified Floating Head Heat Exchanger | TEMA AHS Type, Corrosion-Resistant Alloy Construction

YUHONG ASME VIII-1 Certified Floating Head Heat Exchanger (TEMA AHS Type) combines SA516 Grade.485 carbon steel shell with SA179 cold-drawn seamless tubes to deliver unmatched performance in corrosive and thermally cyclic environments:

SA516 Gr.485 Advantages:

High Strength & Weldability: Carbon-manganese steel plate ideal for pressure vessels (shell/head), offering excellent structural integrity and ease of fabrication.
Low-Temperature Toughness: Normalized + Fine Grain Practice (FGP) ensures impact resistance in harsh operating conditions.

SA179 Advantages:

Superior Thermal Conductivity: Seamless low-carbon steel tubes optimize heat transfer efficiency in exchangers.
Corrosion & Scaling Resistance: Smooth surface finish minimizes fouling, ideal for steam/condenser applications.

SA516 Grade.485 Shell and SA179 Tube Heat Exchanger Material - Shell Side

Component Name	Material	Form	Standard	Supply State
Shell	SA-516M Gr.485	Plate	ASME Sec.Ⅱ-2023 Ed.	Normalized + FGP
Head	-	Plate	-	-
Body Flange	SA-105M	Forging	ASME Sec.Ⅱ-2023 Ed.	Normalized + FGP
Nozzle Neck	SA-106M Gr.B	Pipe	ASME Sec.Ⅱ-2023 Ed.	Hot-Finished
Nozzle Flange	SA-105M	Forging	ASME Sec.Ⅱ-2023 Ed.	Normalized + FGP
Reinforcing Pad	SA-516M Gr.485	Plate	ASME Sec.Ⅱ-2023 Ed.	Normalized + FGP
Couplings	SA-105M	Forging	ASME Sec.Ⅱ-2023 Ed.	Normalized + FGP
Fittings	SA-234M WWB	Pipe	ASME Sec.Ⅱ-2023 Ed.	Hot-Finished

SA516 Grade.485 Shell and SA179 Tube Heat Exchanger Material - Tube Side

Component Name	Material	Form	Standard	Supply State
Shell	SA-516M Gr.485	Plate	ASME Sec.Ⅱ-2023 Ed.	Normalized + FGP
Head	SA-516M Gr.485	Plate	ASME Sec.Ⅱ-2023 Ed.	Normalized + FGP
Body Flange	SA-105M	Forging	ASME Sec.Ⅱ-2023 Ed.	Normalized + FGP
Cover Flange	SA-105M	Forging	ASME Sec.Ⅱ-2023 Ed.	Normalized + FGP
Cover	SA-105M	Forging	ASME Sec.Ⅱ-2023 Ed.	Normalized + FGP
Nozzle Neck	-	Pipe	ASME Sec.Ⅱ-2023 Ed.	Hot-Finished
Nozzle Flange	SA-105M	Forging	ASME Sec.Ⅱ-2023 Ed.	Normalized + FGP
Reinforcing Pad	-	Forging	-	-
Couplings	SA-105M	Forging	ASME Sec.Ⅱ-2023 Ed.	Normalized + FGP
Pass Partition	-	Plate	ASME Sec.Ⅱ-2023 Ed.	Normalized + FGP

ASME VIII-1 Certified Floating Head Heat Exchanger Typical Industries

Petrochemical: Reforming units, hydrotreater heat exchangers
Power: Waste heat recovery systems
Pharmaceutical: High-temperature sterilization processes
